FLO-WELL ENGINEERED DRY WELL We put water in its place
®

NDS # FWAS24C Flo-Well Cover
FLO-WELL ENGINEERED DRY WELL Dimensions mentioned in tables are orientational.
4 5/8" lid height
®
3/4" lip height
21 1/4"Diameter
Check the drawings or technical datasheets for exact dimensions.
All measures shown in drawings are in mm, unless stated otherwise.
Part No. Part No. Wt. Ea. NORMACLAMP ® DRAINAGE SOLUTIONS
US EMEA Description Color Pkg. Qty. (kg) EAN Code
®
117.5 FWAS24CWH 0800 6140 002 61 cm Flo-Well Cover Black 2 2.66 0052063030760
19.1
FWAS24C 0800 0140 001 61 cm Flo-Well Cover Black 2 2.66 0052063003214
®
Specification: Structural foam polyolefin round drywell system cover with UV inhibitors. 189.25 l storage capacity
616.0

Part No. Part No. Wt. Ea.
US EMEA Description Color Pkg. Qty. (kg) EAN Code
Flo-Well 3 Side Panels (assemble into 1 round
®
FWSPS3WH 0800 6140 006 Black 1 1.96 0052063030777
drywell. no bottom)
609.6
Includes 3 side panels; makes 1 round dry well. (May also be used as a durable compost bin)
19.1
Specification: Structural foam polyolefin side panels with UV inhibitors, knockout leaching ports and knockout inlet/outlet
638.2 ports per panel. 1.9 cm lip for firm stacking.

Part No. Part No. Wt. Ea.
US EMEA Description Color Pkg. Qty. (kg) EAN Code
®
FWBP24 0800 6140 003 61 cm Flo-Well Bottom Black 5 1.53 0052063003221
®
Specification: Structural foam polyolefin round Flo-Well bottom with UV inhibitors. Six leaching ports. Collects debris for easy
609.6 cleanout.

161.9
Part No. Part No. Wt. Ea.
US EMEA Description Color Pkg. Qty. (kg) EAN Code
228.6 184.2 FWSD69 0800 6140 005 10.2 cm Surface Drain Inlet with Grate Black 8 0.83 0052063003245
Specification: Structural foam polyolefin grate with inlet with UV inhibitors. Open surface area 53 square centimeters, 95.2 lpm.
114.3

Part No. Part No. Wt. Ea.
US EMEA Description Color Pkg. Qty. (kg) EAN Code
609.6 FWFF67 0800 6140 004 Porous Filter Fabric Wrap for Flo-Well ® Black 1 0.16 0052063003238
®
Specification: For surrounding Flo-Well Drywell System. Nonwoven fabric. Mullen burst 1,206 kPa. 757 LPM flow-through.
2134
