SPEE-D  CHANNEL DRAINS                                                        We put water in its place
                   ®

            SPEE-D  CHANNEL DRAINS – BENEFITS AT A GLANCE
                     ®
            Excellent performance thanks to:
     DRAINAGE SOLUTIONS  Supports aesthetic concept of the landscape and allows for perfect blend-in thanks to:
            •  Quick-fix design
            •  Greater draining surface than Micro and Mini Channel

            •  Multiple colors of grates available: black, white, grey, green, sand and brick red for PVC, raw iron for
               cast iron material
            •  Decorative grate patterns available: botanical and wave
            Easy and precise installation thanks to:
            •  Lightweight elements
            •  Quick-fix design
            •  Possibility of cutting the channel and plastic grates exactly to size





            SPEE-D  CHANNEL DRAINS
                     ®

            Spee-D  Channel Drains – Ideal for residential and commercial applications. Effective in everything from patios, swimming pools and spas to light
                  ®
            vehicular traffic areas.
                     ®
            The Spee-D  Channel systems are lightweight and easy to install and provide a quick and simple alternative to traditional concrete
            channels. The Spee-D  channel drains are available in "1.2" or "3 m" lenghts to easily adapt to any job (Dimensions mentioned are orientational. Check
                           ®
            the drawings or technical datasheets for exact dimensions). Each channel has available accessories that easily connect to a variety of pipe types and
            sizes, such as end outlets, bottom outlets, 90s and tees. This flexibility allows you to easily create a customized drainage system. The channel snaps
            together easily for a smoother installation with flanges on the bottom of the channel providing a lip for anchoring, which ensures a straight installation
            and prevents floating. The NDS Spee-D  Channel grates are available in seven colors, making it easy to match to the surrounding surfaces.
                                     ®





             Product Features

             •  Durable PVC parts are lightweight and easy to install
             •  Component parts snap together easily for a speedy installation
             •  System components are chemically resistant and rustproof
             •  UV inhibitors in the grates and channel






             Spee-D  Channel System Components
                    ®

              1  Channel
              2  Grate
              3  Coupling
                                            2
              4  End Cap or End Outlet
                                                                                               5
              5  Channel Bottom Outlet
                                       4                                       3 3
              6  Sewer and Drain Fitting
                                                                 1                 6                      7
              7  Drain Pipe
