PRO SERIES CHANNEL™ DRAINS We put water in its place

Dimensions mentioned in tables are orientational.
DRAINAGE SOLUTIONS 12.7 cm (5") Pro Series Channel™ Drains (Continued) All measures shown in drawings are in mm, unless stated otherwise.
Check the drawings or technical datasheets for exact dimensions.

Wt. Ea.
Part No.
Part No.
Pkg. Qty.
Color
US
EMEA
EAN Code
(kg)
Description
19.1
12.7 cm x 50.8 cm Pro Series Load Star Heavy
828
0800 6112 016
1.06
0052063808284
Gray
300
Traffic Channel Grate
498.5
9.5 x 31.8 Requires 4 screws per grate. Requires #829 screws. See Class Load Rate Table on page 21.
150.8
Grate Openings
Specification: UV-protected high- impact glass-reinforced nylon Heavy Traffic Channel Grate. Open surface area
PLASTIC
102.7 square centimeters per 30.5 cm. 184.3 LPM per 30.5 cm. Class C load rating.
Part No. Part No. Wt. Ea.
19.1 US EMEA Description Color Pkg. Qty. (kg) EAN Code
12.7 cm x 50.8 cm Pro Series Ductile Iron Channel
823 0800 6112 014 Black 11 5.54 0052063039312
Grate
500 See Class Load Rate Table on page 21.
14.3 x 90.5
NDS#823
Grate Openings Specification: heavy-duty Ductile Heavy Traffic Channel Grate. Open surface area 147.7 square centimeters per 30.5 cm.
133.4
DUCTILE IRON
265.2 LPM per 30.5 cm. Class D load rating.
Part No. Part No. Pkg. Wt. Ea.
US EMEA Description Color Qty. (kg) EAN Code
829 0800 6111 015 Stainless Steel Screws, 6 x 1-1/4" Steel 1 n/a 0052063008295
1000.1 Part No. Part No. Wt. Ea.
US EMEA Description Color Pkg. Qty. (kg) EAN Code
12.7 cm x 1 m Deep Pro Series Profile Channel
5" Modular Pro Series Channel
800 0800 6112 024 Light Gray 10 1.80 0052063080000
(Deep Profile) Drain
139.7
5 1/2"
133.3 Integrated knockout bottom outlet fits 7.62 cm and 10.16 cm S&D fittings.
5 1/4"
19.1 Grate should be recessed 0.32 m below finish grade in non-traffic applications. Grate should be recessed 0.64 m in traffic applications.
3/4"
120.6
4 3/4"
PLASTIC Specification: Deep Profile Channel Drain with mechanical interlocking joints, integrated knockout bottom outlet. Polypropylene.
114.3
4 1/2"
Part No. Part No. Wt. Ea.
120.6 US EMEA Description Color Pkg. Qty. (kg) EAN Code
57.15
811 0800 6112 022 12.7 cm Deep Pro Series Profile End Outlet Light Gray 10 0.18 0052063808116
120.6
57.15
813 0800 6112 021 12.7 cm Deep Profile End Cap/End Outlet Light Gray 10 0.18 0052063808130
120.6
812 0800 6112 020 12.7 cm Deep Profile End Cap Light Gray 10 0.06 0052063808123
414.3 431.8
NDS#712 AI.eps
12.7 cm Deep Pro Series Profile Grate & Channel
861 0800 6112 027 Drain 90° Elbow Light Gray 2 1.55 0052063808611
231.8
16-5/16"
17"
231.8 12.7 cm Deep Pro Series Profile Grate &
862 0800 6112 028 Light Gray 2 1.55 0052063808628
Channel Drain 45° Elbow
#861
50 9-1/8" www.norma-watermanagement.com www.norma-watermanagement.com
9-1/8"
#862
