DURA SLOPE™ TRENCH DRAIN We put water in its place

Accessories Dimensions mentioned in tables are orientational.
Check the drawings or technical datasheets for exact dimensions.
All measures shown in drawings are in mm, unless stated otherwise.

Part No. Part No. Pkg. Wt. Ea. NORMACLAMP ® DRAINAGE SOLUTIONS
US EMEA Description Color Qty. (kg) EAN Code
DS-122 0800 6113 002 ProFit Grate Lock for Dura Slope™ Trench Drain Black 8 0.36 0052063042305
Universal End Outlet downstream for (male) end. Use to attach 0800 6113 005 Ductile Iron Frame to Channel.
Universal End Cap for Dura Slope™ Trench
DS-224 0800 6113 006 Gray 8 0.28 0052063010823
Drain
Suitable for 0800 6190 037 or deeper channels.
Slides into upstream (female) end. Requires 0800 6113 003 screws on downstream (male) end.
DS-227 0800 6113 007 Universal End for Dura Slope™ Trench Drain Gray 6 0.34 0052063010830
Suitable for 0800 6190 037 or deeper channels. Requires 0800 6113 003 screws for use on downstream (male) end.
Bottom Outlet Adapter for Dura Slope™ Trench
DS-126 0800 6113 004 Gray 6 0.24 0052063042312
DS-227 Drain
57.2
Fits to 10.16 cm (4") Sewer and Drain Pipes. 0800 6113 004 not required for Sch. 40 connection.
Use with Grate 0800 6180 085, 0800 6180 086, 0800 6180 087, 0800 6180 081, 0800 6180 083 and 0800 6180 075-079.
Use to secure grates in applications without 0800 6113 005 Ductile Iron Frame.
Drill bit included with each package.

Part No. Part No. Description Color Pkg. Wt. Ea. EAN Code
US EMEA Qty. (kg)
Frame & End Cap Screws for Dura Slope™
DS-123 0800 6113 003 Steel 1 0.00 0052063012391
Trench Drain
629 0800 6111 002 Stainless Steel Screws. 20 x 1-1/2" Steel 1 0.32 0052063041438
Flat Drilled Spanner End Cap Screws for Dura
DS-650 0800 6113 008 Steel 1 0.45 0052063020402
Slope™ Trench Drain

NDS Flexible Coupling Sizing Chart

• All dimensions given in inches and mm.
• Stainless steel clamps supplied with all couplings.
• All couplings will fit any pipe type within +/- 5% OD on chart.

Asbestos cement, fibre, or ductile iron to cast iron or plastic
A B Part No. Part No. Size A Size B Size C Pkg. Weight
US EMEA Description/Connection type Inch mm Inch mm Inch mm Qty. (kg) EAN code
51-44 0800 7670 013 4" AC/DI X 4" CI/PVC 4.75 120 4.38 111 4.00 101 24 0.49 052063010106

C

Cast iron, plastic, copper, steel or lead to cast iron, plastic, copper, steel or lead
A B Part No. Part No. Size A Size B Size C Pkg. Weight
US EMEA Description/Connection type Inch mm Inch mm Inch mm Qty. (kg) EAN code
56-44 0800 7670 026 4" X 4" CI/PVC 4.42 112 4.42 112 4.00 101 24 0.75 052063010113
C To check more details about connection, see page 23.
