CATCH BASINS We put water in its place

CATCH BASINS – BENEFITS AT A GLANCE
DRAINAGE SOLUTIONS Collect surface water and minimize amount of debris entering the system.

Catch basin filter helps prevent dirt and debris from clogging the drainage system.

Cost-effective, cleanable, easy to install and maintain as opposed to the expensive
repair or replacement of drainage system elements.

CATCH BASINS

NDS offers a complete line of catch basins and grates for residential and commercial surface water management solutions. NDS catch basins have sump
areas that collect debris and prevent clogging of the pipeline. Grates are available in a variety of patterns and colors to blend in with surrounding surfaces.
Depending on the size of the round, square or atrium grates, they may fit directly into a riser of pipe, sewer and drain fitting, or our catch basins. To check
Flexible PVC Couplings and adapt products to different pipe sizes, see page 86.

Riser not
always
required

Small Grates Large Catch Basin Adapter

ROLE OF THE FILTER
Clogged pipes reduce the e ectiveness of drainage systems, resulting in standing water and damage to property. Adding a filter is a simple solution to keep
water flowing through a drainage system and a cost-e ective alternative to expensive repair or replacement.

The NDS catch basin filter is removable and cleanable, making it easy to maintain. The filter contains a bypass feature that allows water to flow to the catch
basin even if the filter is full or after a heavy storm water event. The filter comes pre-assembled, making it easy to install: unscrew the grate, drop in the
filter and reinstall the grate. The filter bag is made out of nonwoven, spun-bonded, polypropylene geotextile fabric that provides superior filtration, is inert to
biological degradation and is resistant to naturally encountered chemicals, alkalis and acids. The bag can hold up to 18 kg without tearing and is UV resistant.

Product Features & Benefits

• Prevents dirt and debris from clogging your system
• Available in four sizes, 22.9 cm (9"), 30.5 cm (12"), 45.72 cm (18") and 60.96 cm (24").
Dimensions mentioned are orientational. Check the drawings or technical datasheets for exact dimensions.
• Made from spun-bonded, geotextile fabric
• Unique bypass feature allows for water flow to the catch basin even if the basin is full of leaves, fines, soot, etc.
• Grates available in multiple colors and decorative design patterns
