GRATES                                                                        We put water in its place




            GRATES: STANDARD, DECORATIVE & METAL –
     DRAINAGE SOLUTIONS  Made of solid materials, including cast and ductile iron as well as galvanized steel for
            BENEFITS AT A GLANCE


            higher load demand.
            Supports aesthetic concept of the landscape and allow for perfect blend-in thanks to:
            •  multiple colors available: blue, orange, black, white, grey, silver, bronze, brown, green, sand, brick red
            •  decorative grate patterns available: regular, botanical, wave, diamond, tile, brick, deco
            Versatile flow rate features.






            GRATES: STANDARD, DECORATIVE & METAL


            Our solid cast brass grates are secured to a PVC collar with solid brass screws for aesthetics and reliability. The PVC collar can be solvent welded into
            sewer and drain fittings or pipe where permanent, anti-theft installation is desired. The grate can still be removed for easy cleanout.





             Product Features & Benefits


             •  Strong
             •  Practical
             •  Functional
             •  A unique mix of beauty and function
             •  Recommended for highly-visible entry areas in hotels, malls, office buildings, country clubs and estates
             •  Exceptional construction and fine finish also make these grates ideal for deck areas, walkways, swimming pools and spas





             Materials & Standards  – Brass & Chrome Grates


             •  Made with the highest-quality solid brass
             •  Brushed Satin and Polished Chrome finishes are protected by a clear plastic film that prevents damage to the finish during shipping and
               installation






             Brass & Chrome Grates                                                  Dimensions mentioned in tables are orientational.
                                                                            Check the drawings or technical datasheets for exact dimensions.
                                                                          All measures shown in drawings are in mm, unless stated otherwise.


                                  Part No.   Part No.                                        Wt. Ea.
                                  US       EMEA      Description             Color    Pkg. Qty.   (kg)  EAN Code
                                  552B     0800 6180 095  30.5 cm Brass Channel Grate  Satin Brass  12  0.56  0052063505527
                304.8             553PB    0800 6180 096  30.5 cm Brass Channel Grate  Polished Brass  12  0.56  0052063505534
                             9.5
                                           Fits 0800 6111 036 and 0800 6113 040 Mini Channels. (see page 30). Heel-proof. See Class Load Rate Table on page 21.
                      6.4 x 22.2
                     Grate Opening
          71.4    NDS#552B AI.eps   BRASS  Specification: Mini Channel Solid Brass Grate with brass screws. Open surface area 23.4 square centimeters per 30.5 cm.
                                           106.5 LPM per 30.5 cm. Class A load rating.
