GRATES We put water in its place

Brass & Chrome Grates Dimensions mentioned in tables are orientational.
Check the drawings or technical datasheets for exact dimensions.
All measures shown in drawings are in mm, unless stated otherwise.

Part No. Part No. Wt. Ea. NORMACLAMP ® DRAINAGE SOLUTIONS
US EMEA Description Color Pkg. Qty. (kg) EAN Code
82.5 909B 0800 6180 101 7.6 cm Round Brass Grate w/PVC Collar Satin Brass 20 0.18 0052063390994
905PB 0800 6180 098 7.6 cm Round Brass Grate w/PVC Collar Polished Brass 20 0.18 0052063390550
Fits 7.62 cm (3") Sewer and Drain Fittings. Heel-proof. See Class Load Rate Table on page 21.
34.9
For Flexible PVC Couplings, see page 86.
Specification: Round Solid Brass Grate and brass screws with PVC collar. Open surface area 17.5 square centimeters. 8.20 LPM.
NDS#909B AI.eps
4.7 Grate Opening BRASS Class A load rating.

82.5 Part No. Part No. Wt. Ea.
US EMEA Description Color Pkg. Qty. (kg) EAN Code
915SC 0800 6180 106 7.6 cm Round Chrome Grate w/PVC Collar Satin Chrome 20 0.18 0052063309156
34.9 Fits 7.62 cm (3") Sewer and Drain Fittings. Heel-proof. See Class Load Rate Table on page 21.
For Flexible PVC Couplings, see page 86.
4.8 Grate Opening Specification: Round Solid Chrome Grate and screws with PVC collar. Open surface area 17.3 square centimeters.
NDS#915SC AI.eps
CHROME
31.04 LPM. Class A load rating.

Part No. Part No. Wt. Ea.
US EMEA Description Color Pkg. Qty. (kg) EAN Code
108
910B 0800 6180 103 10.2 cm Round Brass Grate w/PVC Collar Satin Brass 20 0.29 0052063491004
906PB 0800 6180 099 10.2 cm Round Brass Grate w/PVC Collar Polished Brass 20 0.29 0052063490663
44.5
Fits 7.62 cm (3") Sewer & Drain Pipes and 10.16 cm (4") Sewer and Drain Fittings. Heel-proof.
See Class Load Rate Table on page 21. For Flexible PVC Couplings, see page 86.
6.4 Grate Opening Specification: Round Solid Brass Grate and brass screws with PVC collar. Open surface area 33.9 square centimeters. 60.8 LPM.
NDS#909B AI.eps
BRASS
Class A load rating.

Part No. Part No. Wt. Ea.
108 US EMEA Description Color Pkg. Qty. (kg) EAN Code
917SC 0800 6180 107 10.2 cm Round Chrome Grate w/PVC Collar Satin Chrome 20 0.30 0052063409177
908PC 0800 6180 100 10.2 cm Round Chrome Grate w/PVC Collar Polished Chrome 20 0.30 0052063490885
44.5
Fits 7.62 cm (3") Sewer & Drain Pipes and 10.16 cm (4") Sewer and Drain Fittings. Heel-proof.
See Class Load Rate Table on page 21. For Flexible PVC Couplings, see page 86.
NDS#917SC AI.eps
6.4 Grate Opening
Specification: Round Chrome Grate and screws with PVC collar. Open surface area 33.9 square centimeters. 60.8 LPM.
CHROME
Class A load rating.

Part No. Part No. Wt. Ea.
US EMEA Description Color Pkg. Qty. (kg) EAN Code
169.9
918B 0800 0180 015 15.2 cm Round Brass Grate w/Styrene Collar Satin Brass 8 0.62 0052063409184
919PB 0800 6180 109 15.2 cm Round Brass Grate w/Styrene Collar Polished Brass 8 0.62 0052063409191
50.8 Fits Spee-D Basin and 15.24 cm (6") Sewer and Drain Fittings. Heel-proof. See Class Load Rate Table on page 21.
®
For Flexible PVC Couplings, see page 86.
Specification: Round Solid Brass Grate and brass screws with styrene collar. Open surface area 84.5 square centimeters.
9.5 Grate Opening BRASS
NDS#918B AI.eps
151.7 LPM. Class A load rating.
