GRATES We put water in its place

Dimensions mentioned in tables are orientational.
DRAINAGE SOLUTIONS Brass & Chrome Grates (continued) Description All measures shown in drawings are in mm, unless stated otherwise.
Check the drawings or technical datasheets for exact dimensions.

Wt. Ea.
Part No.
Part No.
120.6
EMEA
EAN Code
US
Color
(kg)
Pkg. Qty.
0800 6180 104
12.7 cm Square Brass Grate w/PVC Collar
0.54
0052063591308
10
Satin Brass
913B
44.5
4.8 914PB 0800 6180 105 12.7 cm Square Brass Grate w/PVC Collar Polished Brass 10 0.54 0052063591407
Fits 10.16 cm (4") Sewer and Drain Fittings. See Class Load Rate Table on page 21. For Flexible PVC Couplings, see page 86.
104.8
NDS#913B AI.eps
9.5 Grate Opening Specification: Square Solid Brass Grate with brass screws and PVC collar. Open surface area 16.125 square centimeters.
BRASS
29 LPM. Class A load rating.
Part No. Part No. Wt. Ea.
US EMEA Description Color Pkg. Qty. (kg) EAN Code
920B 0800 6180 110 15.2 cm Square Brass Grate w/Styrene Adapter Satin Brass 8 0.74 0052063309200
155.6
923PB 0800 6180 113 15.2 cm Square Brass Grate w/Styrene Adapter Polished Brass 8 0.74 0052063409238
Fits 7.62 cm (3") and 10.16 cm (4") Sewer and Drain Fittings. See Class Load Rate Table on page 21.
69.9 For Flexible PVC Couplings, see page 86.
22.2
NDS#920B AI.eps Specification: Square Solid Brass Grate with brass-colored styrene low-profile adapter and brass screws. Open surface area 74.82
100.0 BRASS
9.5 Grate Opening square centimeters. 134.3 LPM. Class A load rating.
Part No. Part No. Wt. Ea.
US EMEA Description Color Pkg. Qty. (kg) EAN Code
155.6 921B 0800 6180 111 15.2 cm Square Brass Grate w/Styrene Adapter Satin Brass 8 0.77 0052063409214
922PB 0800 6180 112 15.2 cm Square Brass Grate w/Styrene Adapter Polished Brass 8 0.77 0052063409221
®
69.9 Fits Spee-D Basin and 15.24 cm (6") Sewer and Drain Pipes and Fittings. See Class Load Rate Table on page 21.
For Flexible PVC Couplings, see page 86.
19.1
176.2 Specification: Square Solid Brass Grate with brass-colored styrene low-profile adapter and brass screws. Open surface area 74.82
NDS#921B AI.eps
9.5 Grate Opening BRASS square centimeters. 134.3 LPM. Class A load rating.

Part No. Part No. Wt. Ea.
US EMEA Description Color Pkg. Qty. (kg) EAN Code
28.6 225.4 11.1 Grate 930B 0800 6150 024 22.9 cm Square Brass Grate Brass 3 2.30 0052063018072
Openings
See Class Load Rate Table on page 21.
BRASS Specification: Open surface area 219.3 square centimeters. 393.7 LPM. Includes SS Screws. Class B load rating.

Part No. Part No. Wt. Ea.
9.5 Grate
298.5 US EMEA Description Color Pkg. Qty. (kg) EAN Code
Openings
1230B 0800 6150 066 30.5 cm Square Brass Grate Brass 4 4.16 0052063019307
28.6
See Class Load Rate Table on page 21.
BRASS Specification: Open surface area 276.5 square centimeters. 496.3 LPM. Includes SS Screws. Class B load rating.
NDS#1210 AI.eps
